[Docker] Let's Learn About Docker Compose

Brothers, am I the only one uncomfortable?

This is the second brothers. There are actually many uncomfortable things.

Use of Docker

When did they say we use Docker?

It would be when you want to use the core technology of Docker, Container.

In other words, for reuse.

The Dockerfile we learned earlier automated many parts required to create a container.

However, there are also disadvantages to Dockerfile.

As discussed in the previous post, there were limitations in automating the settings of the Host OS.

For example, it couldn’t reach port forwarding of the Host OS or mounting the path of the volume.

Eventually, many developers would create a Dockerfile, connect containers created through build, and mount volume.

Docker Compose

Docker Compose solves the above issues.

The details that can be defined in docker-compose.yml include volume, port, env as well as support for performing various operations to define containers.

It also not only defines a single container, but also supports the definition of multiple containers and setting relationships between containers.

The official Docker documentation introduces Compose as a container-based application that is platform-agnostic.

.yml, .yaml

Before learning about Docker Compose, there is something to know.

Earlier, it was stated that docker-compose.yml can be used to set commands for multiple containers.

So, what is a .yml file?

Files with .yml, .yaml extensions are a form of markup language called Yet Another Markup Language.

It forms a hierarchy through colons and indentation like Python, allowing easy writing of specific objects, configuration values, etc.

To intuitively understand, let’s look at the example below.

car:
  name: "bus"
  color: "red"
  door: 4
  capability:
    max_weight: "4T"
    human: 10
  customers:
    - name: "Alice"
      age: 14
    - name: "Ban"
      age: 16
    - name: "Yang"
      age: 26

This form of .yaml can also be expressed in the same JSON format as below.

{
  "car": {
    "name": "bus",
    "color": "red",
    "door": 4,
    "capability": {
      "max_weight": "4T"
    }
  }
}

In this way, .yml is a file format that is convenient to use when expressing data in a hierarchical form, using existing formats such as JSON and XML.

docker-compose.yml

Now let’s create docker-compose.yml and specify the containers we will use.

services

First, the specification for each container we define is defined as a unit called service.

If you explain using the .yml format, it would be this format.

services:
  container_1:
    ...
  container_2:
    ...


This is the part where the image to be retrieved is specified.

There are various ways to retrieve the desired image.

# Image name
image: redis
# Image name: tag name
image: redis:5
# Image name@sha256: IMAGE ID
image: redis@sha256:0ed5d5928d4737458944eb604cc8509e245c3e19d02ad83935398bc4b991aac7
# Repository name/image name
image: library/redis
# Registry name/repository name/image name
image: docker.io/library/redis
# Private registry address:port/image name
image: my_private.registry:5000/redis

build

This is used when you want to create a container through Dockerfile.

services:
  frontend:
    image: awesome/webapp
    build: ./webapp # Acts as context if sub-levels are not specified

  backend:
    image: awesome/database
    build:
      context: backend # Path to search for Dockerfile
      dockerfile: ../backend.Dockerfile # Specify the file name if it is not Dockerfile

  custom:
    build: ~/custom # "~" can also be used to specify the home directory

1. The awesome/webapp image is built using the ./webapp subdirectory in the same folder as the Compose file as the docker build context. An error occurs if there is no Dockerfile in this folder.
2. The awesome/database image is built using the ./backend subdirectory in the same folder as the Compose file. The backend.Dockerfile file is used to define the build stage, and this file (backend.Dockerfile) is defined based on the context path (./backend). In this sample, it is interpreted as the parent folder of the Compose file, so the sibling Dockerfile of backend.Dockerfile is also a search target.
3. The custom service is built using custom directory in the user’s HOME directory as the context.

When image and build are both present

It was said that image creates a container based on the specified image, and build creates a container using Dockerfile.

However, since it is possible to retrieve an image through the FROM keyword in Dockerfile, one might worry whether these properties might conflict.

You can also find a section on this in the official Docker documentation, confirming our worry that there is no guarantee of which image will be used.

Unless indicated otherwise by the user, it states that it first retrieves the image defined in image and builds the image from the Dockerfile if an image cannot be found in the registry.

depends-on

When defining multiple services in docker-compose.yml, if a certain service needs to start after a particular service has started, you can specify it with depends_on: service name.

services:
  seviceA:
    ...
    depends_on: serviceB

  serviceB:
    ...

entrypoint

Performs the same role as ENTRYPOINT discussed in the Dockerfile.

In other words, it defines the initial command to execute when the Docker container runs.

As covered in the previous chapter, since this command can be declared only once, if ENTRYPOINT is also specified in the Dockerfile through the build option, one (or both) must be deleted.

In many cases, it seems that it is used to define which shell to use initially.

entrypoint: /code/entrypoint.sh

labels

As covered in the LABEL section of the Dockerfile, it’s an item that allows adding metadata to the container.

environment

It’s used when defining environment variables to be used in the container.

Two methods can be used.

1. Map method

environment:
  RACK_ENV: development
  SHOW: "true"
  USER_INPUT: "hello"

2. Array method

environment:
  - RACK_ENV=development
  - SHOW=true
  - USER_INPUT=hello

env_file

If you want to define environment variables in a file rather than direct definition, use this option.

env_file: some_env.env

# some_env.env
RACK_ENV=development
VAR="quoted"

When using this method, you can manage environment variables in the form of a file, which has the advantage of easier management.

command

Like we learned in the CMD section of the Dockerfile, it’s the part where we define commands to give to the container responsible for the service.

command: ls -al

Since I’m a backend developer, I’ll describe the difference between the two commands (Dockerfile:CMD, docker-compose.yml:command) from a backend developer’s perspective.

CMD of the Dockerfile is generally used for commands to install basic components to configure the server such as pip install, gradle build.

Think of it as making it in a form that can run the container (but it’s not mandatory to follow this strictly).

command of docker-compose.yml is often used for commands that deploy servers (e.g. ... run serve) as in commands that run the service.

volumes

volumes is used to define connecting the user’s created Docker Volume or Host Path and Container Path, or declaring a volume itself.

Specification of volume

The method to define the sub-elements of volumes combines two types of notation: shorthand and normal syntax.

Generally, shorthand is used but the standard syntax can also be used depending on the circumstances or user’s preference.

1. Normal syntax elements

    ...
    volumes:
      - type: volume
        source: db-data
        target: /data
    ...

2. Shorthand notation

Designate using the format VOLUME:CONTAINER_PATH:ACCESS_MODE.

ACCESS_MODE is set to rw by default.

services:
  service_1:
    image: some/image
    # Connecting Docker Volume and Container Path
    volumes:
      - db-data:/etc/data

  service_2:
    image: some/image
    # Connecting Host OS's Path and Container Path
    volumes:
      - .:/var/lib/backup/data

  service_3:
    image: some/image
    # Connecting Host OS's Path and Container Path and setting Container Path to read-only
    volumes:
      - .:/var/lib/backup/data:ro

Defining Volume

If you want to define a Volume through volumes, place volumes as the top-level element of docker-compose.yml.

# Define Docker Volume
volumes:
  db-data:

ports

Operates in the same way as the -p option used in run and create of the Docker CLI. It maps the Port of Host OS and Port of Container Path.

    ...
    ports:
      - "8000:8000"
    ...

In the configuration above, all requests coming to port 8000 of the Host OS will instead be forwarded to port 8000 of the Container.

Docker Compose CLI

Now all that’s left is to create the container.

Using the docker-compose up command will find and automatically execute the docker-compose.yml file in the specified directory.

In the newly released Docker Compose V2, it specifies to use the docker compose keyword to execute, so keep this in mind if using V2.

The -d option enables the service to run in background mode. (Commonly used)

The -f [COMPOSE_FILE_NAME] option allows you to run Docker Compose through a specific file other than docker-compose.yml.

The docker-compose start [SERVICE_NAME] command allows you to run a specific service within the services.

Conversely, the docker-compose stop [SERVICE_NAME] command is used to stop a specific service.

Reference

• Docker Official Documentation - Compose file Reference
• Docker Official Documentation - Docker Compose CLI Reference
